A NEW STANDARD OF RELIABLITY IN MOISTURE MEASUREMENT

Available at Alpha Process Sales - TX & LA & Murray Energy - Texas


Kahn manufactures a full line of precision hygrometers using the most advanced, proven technologies:

• Ceramic sensors yield the fastest response time and greatest corrosion resistance

• Extremely accurate chilled mirror optical systems provide a fundamental method of dewpoint measurement

Kahn features intrinsically safe designs for hazardous locations. All Kahn hygrometers offer traceability to national and international standards.

LEARN MORE

HG-1 Humidity Generator
HG-1 Humidity Generator

HG-1 Humidity Generator

press to zoom
SOFTWARE
SOFTWARE

SOFTWARE

press to zoom
Easidew PRO XP (Explosion Proof) Moisture Transmitter
Easidew PRO XP (Explosion Proof) Moisture Transmitter

Easidew PRO XP (Explosion Proof) Moisture Transmitter

press to zoom
HG-1 Humidity Generator
HG-1 Humidity Generator

HG-1 Humidity Generator

press to zoom
1/17

KAHN INS. FEATURED PRODUCT

INTRINSICALLY SAFE PORTABLE HYGROMETER

A fast-responding, easy to use, portable hygrometer for measurement of dewpoint and moisture content of compressed air and other gases.

Simple Operation: The menu-driven display, easily accessible gas connections and application software allow the user to quickly and easily set up the HygroPort and make measurements within minutes. All measurement parameters are available at the touch of a button. The numerous features are easy to navigate with our intuitive interface and multiple, large LCD displays.


Features & Benefits

  • FM/CSA certified for Class I, Division 1, Groups A, B, C, D hazardous environments

  • Dewpoint measurements from -148°F to +68°F; ±1.8°F typical dewpoint accuracy

  • Fast-responding internal ceramic sensor

  • Second process input channel for external transmitter

  • Internal data logging facility (log up to 320,000 points)

  • Bluetooth wireless interface to application software

  • 1/8" NPT inlet and outlet gas connections; stainless steel gas wetted parts

  • Pressure compensated PPMv, Lb/MMSCF or g/m3 measurements

  • 50 micron stainless steel sintered disk filter in the inlet port

CERAMIC SENSOR HYGROMETERS

Kahn pioneered the use of ceramic substrate sensors to meet the need for accelerated response and for measuring dewpoints in mildly corrosive gases. The result is a ceramic sensor that not only provides the fastest documented response to dewpoint changes, but also uses a sintered ceramic base material and innovative film deposition techniques to improve chemical and mechanical resistance to corrosive gases. In addition, Kahn sensors are very stable and are not harmed by contact with water. All ceramic sensors are fully interchangeable without the need for hygrometer recalibration.
Cermet II Hygrometer
  • Dewpoints from -148°F to +68°F

  • Pressures to 5000 PSIG

  • °C, °F, #/MMSCF and PPMV

  • 4-20mA and 0-10 VDC outputs

  • Up to four alarm setpoints

  • Second process input (temperature or pressure)

  • Open sensor alarm

Download

Easidew Hygrometer
  • Dewpoints from -148°F to +68°F

  • Display °F or °C dewpoint or PPMv moisture content

  • 4-20mA analog and RS485 digital outputs

  • Two adjustable setpoint alarm relays; optional 3rd alarm relay

  • Vacuum to 6500 PSIG sensor operating pressure

  • NEMA 4 sensor housing

Download

Easidew Transmitter
  • Dewpoints from -148°F to +68°F

  • Accuracy to ±3.6°F

  • Pressures to 5000 PSIG

  • 4-20mA output

  • Small footprint

 Download

Easidew I.S. (Intrinsically Safe) Dewpoint Transmitter
  • Class I, Division 1, Groups A, B, C, D

  • Dewpoints from -148°F to +68°F

  • Accuracy to ±3.6°F

  • Pressures to 5000 PSIG

  • 4-20mA outputs

  • Temperature compensation

Download

Easidew PRO I.S. (Intrinsically Safe) Dewpoint Transmitter
  • FM/cCSAus certified for Class I, Division 1, Groups A, B, C, D hazardous environments

  • Heavy duty, process type NEMA 4 enclosure

  • Dewpoints from -148°F to +68°F

  • 4-20mA output configurable in °F, °C, or PPMv

  • 2-wire, loop-powered operation

  • Dewpoint accuracy of ±3.6°F

  • Pressures to 5000 PSIG

Download

Easidew PRO I.S. (Intrinsically Safe) Hygrometer
  • FM/cCSAus certified for Class I, Division 1, Groups A, B, C, D hazardous environments

  • Heavy duty, process type NEMA 4 sensor housing

  • Dewpoints from -148°F to +68°F; ±3.6°F dewpoint accuracy

  • Dual alarm relays and scalable 4-20mA or 0-10 VDC output

  • Includes digital display, I.S. dewpoint sensor, Galvanic Isolation Interface and sensor cable

  • Manual or auto pressure compensated PPMv, Lb/MMSCF or g/m3 measurement

  • Pressures to 5000 PSIG

  • Open sensor alarm

Download

Easidew PRO XP (Explosion Proof) Moisture Transmitter
  • CSA, ATEX, IECEx, certified for Class I, Division 1, Groups A, B, C, & D

  • Dewpoints from -166°F to +68°F (-110°C to +20°C)

  • 4-20 mA linear, configurable output signal

  • Rugged NEMA 4 weatherproof housing

  • 0-3000 PPMv moisture content in gas

  • 0-1000 PPMw moisture content in liquid

  • Explosion proof and flame proof

  • 2-wire, loop-powered operation

  • Dewpoint accuracy to ±1.8°F

  • 14 to 28 VDC operation

  • Pressures to 6500 PSIG

  • Dual conduit entry

 Download

SF82 Dewpoint Transmitter
  • Rugged design for wet environments and high humidity

  • -76°F to +140°F (-60°C to +60°C) dewpoint range

  • 0 to 24,000 PPMv moisture content

  • Linear 4-20 mA signal, MODBUS RTU digital output (optional)

  • 2-wire loop powered configuration

  • Accuracy to ±3.6°F

  • NIST traceable

Download

Pura High Purity Gas Dewpoint Transmitter
  • Measure trace moisture in high purity gases

  • Dewpoints from -184°F (<1ppbv) to -40°F

  • VCR gas connection ports

  • 4-20mA and RS485 outputs

  • Pressures from 10-9 Torr to 3500 PSIG

  • Internal 0.25 Ra µm electro-polished finish

  • Fast response

Download

HygroPort Portable Hygrometer
  • Dewpoints from -148°F to +68°F

  • Rugged thermoplastic case; NEMA 4 rated

  • Digital display, user selectable ranges and units

  • Fast-responding internal sensor

  • Second process input channel (4-20 mA) for external transmitters

  • Internal data logging facility (log up to 320,000 points)

  • Bluetooth wireless interface to application software

  • 1/8" NPT inlet and outlet gas connections; stainless steel gas wetted parts

  • 20 micron stainless steel sintered disk filter in the inlet port

  • Pressure and temperature compensation capabilities

Download

HygroPort I.S. (Intrinsically Safe) Portable Hygrometer
  • FM/CSA certified for Class I, Division 1, Groups A, B, C, D hazardous environments

  • Dewpoint measurements from -148°F to +68°F; ±1.8°F typical dewpoint accuracy

  • Fast-responding internal ceramic sensor

  • Second process input channel for external transmitter

  • Internal data logging facility (log up to 320,000 points)

  • Bluetooth wireless interface to application software

  • 1/8" NPT inlet and outlet gas connections; stainless steel gas wetted parts

  • Pressure compensated PPMv, Lb/MMSCF or g/m3 measurements

  • 50 micron stainless steel sintered disk filter in the inlet port

Download

 Easidew Plus Portable Hygrometer
  • Dewpoints from -58°F to +68°F

  • Accuracy to ±3.6°F

  • Pressures to 4300 PSIG

  • Exceptionally fast response

  • °F or °C display

  • Integrated sample system

  • NEMA 6 enclosure

Download

HygroPort Portable Hygrometer.jpg
Pura High Purity Gas Dewpoint Transmitte
Easidew Plus Portable Hygrometer.jpg


OPTICAL CHILLED MIRROR HYGROMETERS

These instruments thermo-electrically chill a mirror surface until dew or frost begins to form, providing the most fundamental measurement of dew or frostpoint. Formation of dew or frost is precisely monitored by an electro-optical system; measurements are traceable to national and international standards. To account for the buildup of contaminants on the mirror surface, Kahn's system incorporates Automatic Balance Compensation (ABC). Periodically, the instrument automatically heats the mirror to vaporize the accumulated dew or frost, recalibrates itself for altered reflectivity due to contaminants, then returns to normal measuring.
Optidew Optical Dewpoint and RH Transmitter
  • Dewpoint, temperature and RH measurement
    Fundamental method of dewpoint and RH measurement
    Range:-40°F to +248°F; 0.45 to 100% RH
    Accuracy of ± 0.27°F
    Single, two stage and harsh environment sensor options
    Dual 4-20mA outputs; Alarm relay

Download

Optisure Optical Hygrometer
  • Dewpoints from -76°F to +104°F
    Fundamental method of dewpoint measurement
    Accuracy to ± 0.18°F
    Internal and remote sensor options
    Dynamic Contamination Correction (DCC)
    4-20mA, 0-20mA, and 0-1 VDC outputs
    USB, MODBUS RTU digital outputs

Download



CALIBRATION EQUIPMENT

Kahn offers off-the-shelf and custom designed calibration equipment to allow independent verification of the accuracy of your Kahn or other brand humidity sensors. We can design an entire system for you or you can purchase a fully capable, standard system.
Opti-Cal Humidity Calibrator

Stand-alone calibrator for relative humidity (RH) sensors providing automated humidity and temperature profiling with a built-in, NIST traceable, optical reference hygrometer.

  • Perform RH sensor calibration in-house

  • Digital control of temperature and relative humidity

  • Range 10% to 90% RH from 10° to 50°C chamber temperatures

  • Large, 122 cubic inch chamber

  • Integrated, precision, reference hygrometer with Windows application software

  • Best RH measurement capability <2% of reading

Download

HG-1 Humidity Generator

Bench-mount calibrator for manual calibration of relative humidity and dewpoint sensors including aluminum oxide, ceramic and optical probes.

  • Manual calibration of dewpoint and relative humidity

  • Range 10% to 90% RH and -50°C to +50°C dewpoint

  • Accomodates up to 6 sensors

  • Integrated, precision, reference hygrometer

  • Best RH measurement capability <2% of reading; best dewpoint measurement capability ±0.2°C

Download
